Ntshiab Molybdenum Sheets
Engineered for Excellence: Tsim los rau cov neeg tsim pwm, siab -kub rau cov neeg tsim khoom, thiab cov chaw tsim khoom lag luam uas xav tau cov ntawv pov thawj refractory hlau nrog kev ruaj ntseg zoo thiab kev ua haujlwm zoo dua.
- Khoom Taw qhia
Hwm Ntshiab Molybdenum Ntawv|Technical Data & Ntiaj teb no Supply
Engineered rau Excellence:Tsim los rau cov neeg tsim pwm, siab - cov neeg tsim hluav taws xob kub, thiab cov chaw tsim khoom lag luam uas xav tau cov ntawv pov thawj refractory hlau nrog kev ruaj ntseg zoo thiab kev ua haujlwm zoo dua.
Khoom Specifications & Chemical Composition
Peb cov nplooj ntawv yog tsim los ntawm cov hmoov metallurgy siab heev (compacting, sintering, thiab multi-dav dov) siv 100% nkauj xwb raw cov ntaub ntawv los xyuas kom meej qhov siab tshaj plaws purity thiab structural kev ncaj ncees.
• Khoom Qib: Ntshiab Molybdenum (Mo 1)
• Chemical Purity: >= 99.95% Mo (Interstitial impurities xws li Fe, Ni, Al, Si, C, N, thiab O yog nruj tswj hwm ntawm nruj ppm txwv)
• Ceev: Kwv yees li . 10.2 g/cm3
• Melting Point: 2623 deg C (4753 deg F)
• Cov Qauv Zoo & Ua Raws Cai: ASTM B386, GB / T 3876, ISO 9001 Certified Manufacturing, RoHS & REACH Raws
Lub cev & Thermal Properties
• Thermal conductivity: Kwv yees . 138 W/(m·K) ntawm chav tsev kub
• Coefficient ntawm Thermal Expansion (CTE): 5.1 x 10^-6 /K (ntawm chav tsev kub)
Standard & Custom Dimensions
|
Parameter |
Ntau Ntau Yam & Cov Cai Ua Lag Luam |
|
Thickness |
0.05mm txog 10.0mm (Ntau cov khoom muaj rau cov ntsuas ntsuas) |
|
Dav |
Max mus txog 600 mm (nyob ntawm thickness) |
|
Ntev |
Custom cut-rau-ntev mus txog 2000 mm lossis coil hom rau ultra-thin gauges |
|
Tolerances |
Tsim kom nruj ASTM B386 tus qauv tolerances; nruj dua kev cai kam rau ua muaj raws li qhov kev thov |
|
MOQ & Lub Sijhawm Ua Haujlwm |
MOQ: Saj zawg zog (Prototypes, qauv kuaj, thiab bulk zeb khiav txhawb). Lub Sijhawm Lead: 3-5 hnub ua haujlwm rau cov qauv Tshuag; 7-15 hnub rau kev cai ua. |
Nto Finish Options
Tailor daim ntawv mob ncaj qha rau koj cov txheej txheem tsim khoom:
Rolled Surface (Mill Finish):Retains ntuj zeb tiav; zoo tagnrho rau downstream stamping, sib sib zog nqus nqus, los yog dav fabrication.
Polished nto:Mechanically hauv av kom txo tau qhov roughness (Ra), tshem tawm me me dov cov cim rau kev siv kho qhov muag tshwj xeeb lossis cov cuab yeej siv.
Chemically Cleaned / Alkali Ntxuav:Deg oxides, ua lubricants, thiab graphite residues raug tshem tawm kom huv si ntawm cov tshuaj etching. Pom zoo heev rau lub tshuab nqus tsev vacuum internals thiab semiconductor cleanroom ib puag ncig.
Tus nqi -Ntxiv cov txheej txheem & Cov ntawv thov tseem ceeb
Dhau li ntawm cov ntaub ntawv nyoos, peb nyob rau hauv -lub tsev engineering thiab fabrication muaj peev xwm tso cai rau peb xa nyob ze -net{2}} cov khoom siv ncaj qha los ntawm koj CAD/DXF kos duab los ntawm laser txiav, waterjet txiav, thiab precision shearing.
Yas Txhaj Moulds:Siv raws li siab -conductivity pwm inserts thiab core pins nyob rau hauv thermal bottleneck aav, capitalizing ntawm tsawg thermal expansion kom muaj micron - theem ib feem nyob rau hauv lub sij hawm sai thermal cycling.
Lub tshuab nqus tsev & siab -Tub kub rauv:Cov kws tshaj lij tau tsim rau hauv cov ntaub thaiv hluav taws xob, cov khoom siv cua sov, cov nkoj sintering, thiab cov khoom siv hluav taws xob txhawb nqa muaj peev xwm ua haujlwm tsis tu ncua siab tshaj 1200 ° C hauv inert lossis siab - nqus cua.
Electronics & Semiconductor:Precision- stamped rau hauv cov hluav taws kub sib kis, cov nkoj evaporation, thiab cov phaj hauv qab uas tshwj xeeb thermal conductivity thiab ultra- tsis tshua muaj outgassing yog qhov yuav tsum tau ua.
Kev Tswj Xyuas Zoo & Cov Ntaub Ntawv
Txhawm rau lav qhov kev ntseeg tau zoo nyob rau hauv siab - ib puag ncig cov ceg txheem ntseeg, txhua qhov ntau lawm tau ua tiav ntau yam - theem tshuaj xyuas:
Tshuaj ntsuam xyuas:Spectrographic testing verifying molybdenum assay (>= 99.95%).
Dimensional soj ntsuam:High -precision micrometer thiab caliper checks rau cov tuab tuab, meej dav, ntev, thiab ntug ncaj.
Mechanical & Visual Screening:Kev ntsuam xyuas flatness, kev tshuaj ntsuam xyuas qhov tsis xws luag (kuaj xyuas cov laminations, micro- tawg, lossis hnyav oxidation), thiab kuaj hardness.
Tag nrho Traceability:Txhua qhov khoom xa tuaj yog nrog rau daim ntawv pov thawj Mill Test Certificate (MTC) sib piv cov cua sov thiab ntau tus lej.
FAQ
Q: Dab tsi yog daim ntawv pov thawj purity ntawm koj cov nplooj ntawv molybdenum?
A: Our pure molybdenum sheets maintain a guaranteed minimum purity of >= 99.95% Mo, nrog nruj tswj hwm cov ntsiab lus interstitial kom paub meej tias qhov ntsuas kub ua haujlwm siab -.
Q: Dab tsi kev lag luam feem ntau siv koj cov ntawv molybdenum?
A: Lawv tau hais dav dav los ntawm cov kws tshaj lij thoob ntiaj teb rau cov yas txhaj tshuaj pwm, kev tsim kho lub tshuab nqus tsev, cov cuab yeej ua haujlwm semiconductor, hluav taws xob / tshav kub tiv thaiv, thiab cov khoom siv dav hlau.
Q: Koj puas tuaj yeem ua raws li qhov ntau thiab tsawg thiab tsis yog - tus qauv qhov ntev?
A: Yog. Peb tshwj xeeb hauv kev tsim khoom, muab cov thicknesses, dav, ntev, thiab tshwj xeeb nto finishes ua nruj me ntsis rau koj technical drawings.
Q: Vim li cas thiaj xaiv cov ntawv molybdenum rau kev txhaj tshuaj molding?
A: Molybdenum ua ke zoo heev thermal conductivity nrog ib tug tsawg coefficient ntawm thermal expansion. Qhov no tiv thaiv warping, tshem tawm qhov kub ntawm qhov chaw, thiab khaws cia ib feem ntawm kev ua siab ntev los ntawm ntau txhiab qhov kev txhaj tshuaj sai.
Q: Dab tsi thoob ntiaj teb cov qauv ua koj cov khoom ua raws?
A: Peb cov txheej txheem tsim khoom ua tau raws li ASTM B386 thiab GB / T 3876 tus qauv, txhawb nqa los ntawm ISO- cov txheej txheem ntawv pov thawj thiab tag nrho RoHS & REACH ua raws rau seamless thoob ntiaj teb xa tawm.
Q: Cov nplooj ntawv molybdenum piv rau cov ntawv tungsten li cas?
A: Molybdenum offers a significantly lower density and superior machinability compared to tungsten, making it much easier to fabricate while still providing exceptional high-temperature strength. Tungsten feem ntau yog tshwj tseg rau qhov kub thiab txias tiv thaiv los yog hnyav hluav taws xob tiv thaiv.
Cim npe nrov: Tuam Tshoj ntshiab molybdenum nplooj ntawv manufacturers, lwm tus neeg, Hoobkas
